Results:

Photo Mfr. Part # Availability Price Quantity Datasheet Packaging Series ProductStatus TransformerType Inductance ET(Volt-Time) TurnsRatio-Primary:Secondary MountingType Size/Dimension Height-Seated(Max)

IL-10-0001

IL-10-0001

IL5 PULSE TRANSFORMER THT 0.1A

2,688

-

RFQ

IL-10-0001

Datasheet

Bulk

IL

Active

SCR and Triac Trigger (Encapsulated)

2.5mH

250VµS

1:1:1

Through Hole

0.689 L x 0.728 W (17.50mm x 18.50mm)

0.453 (11.50mm)

IL-11-0002

IL-11-0002

IL1 PULSE TRANSFORMER THT 0.25A

2,233

-

RFQ

IL-11-0002

Datasheet

Bulk

IL

Active

Isolation and Data Interface (Encapsulated)

2.5mH

-

1:1

Through Hole

0.689 L x 0.728 W (17.50mm x 18.50mm)

0.453 (11.50mm)
